The Explorer-class heliocentric spacecraft, ISEE 3 (International
Sun-Earth Explorer 3), was part of the mother / daughter / heliocentric mission (ISEE 1, ISEE 2, and ISEE 3). In 1982 it was re-purposed as a cometary probe and renamed ICE (International Cometary Explorer).
The purposes of the mission were:
- to investigate solar-terrestrial relationships at the outermost boundaries of the
Earth's magnetosphere;
- to examine in detail the structure of the solar wind near the Earth and the shock wave
that forms the interface between the solar wind and Earth's magnetosphere;
- to investigate motions of and mechanisms operating in the plasma sheets; and,
- to continue the investigation of cosmic rays and solar flare emissions in the
interplanetary region near 1 AU.
The three spacecraft carried a number of complementary instruments for making
measurements of plasmas, energetic particles, waves, and fields. The mission thus extended
the investigations of previous IMP spacecraft. The launch of three coordinated spacecraft
in this mission permitted the separation of spatial and temporal effects. This
heliocentric spacecraft had a spin axis normal to the ecliptic plane and a spin rate of
about 20 rpm. It was initially placed into an elliptical halo orbit about the Lagrangian
libration point (L1) 235 Earth radii on the sunward side of the Earth, where it
continuously monitored changes in the near-Earth interplanetary medium. In conjunction
with the mother and daughter spacecraft, which had eccentric geocentric orbits, this
mission explored the coupling and energy transfer processes between the incident solar
wind and the Earth's magnetosphere. In addition, the heliocentric ISEE 3 spacecraft also
provided a near-Earth baseline for making cosmic-ray and other planetary measurements for
comparison with corresponding measurements from deep-space probes. ISEE 3 was the first
spacecraft to use the halo orbit.
In 1982 ISEE 3 began the magnetotail and comet encounter phases of its mission. A maneuver was conducted on 10 June 1982, to remove the spacecraft from the halo orbit around the L1 point and place it in a transfer orbit involving a series of passages between Earth and the L2 (magnetotail) Lagrangian libration point. After several passes through the Earth's magnetotail, with gravity assists from lunar flybys in March, April, September and October of 1983, a final close lunar flyby (119.4 km above the moon's surface) on 22 December 1983, ejected the spacecraft out of the Earth-Moon system and into a heliocentric orbit ahead of the Earth, on a trajectory intercepting that of Comet Giacobini-Zinner. At this time, the spacecraft was renamed ICE (International Cometary Explorer). A total of fifteen propulsive maneuvers (four of which were planned) and five lunar flybys were needed to carry out the transfer from the halo orbit to an escape trajectory from the earth-moon system into a heliocentric orbit.
The primary scientific objective of ICE was to study the interaction between the solar
wind and a cometary atmosphere. As planned, the spacecraft traversed the plasma tail of
Comet 21P/Giacobini-Zinner on 11 September 1985, and made in situ measurements of
particles, fields, and waves. It also transited between the Sun and Comet 1P/Halley in
late March 1986, when other spacecraft (Giotto, Planet-A, MS-T5, Vega 1 and 2) were
also in the vicinity of Comet 1P/Halley on their comet rendezvous missions. ICE became the
first spacecraft to directly investigate two comets.
Tracking and telemetry support have been provided by the DSN (Deep Space Network) since
January 1984. The ISEE-3/ICE bit rate was nominally 2048 bps during the early part of the
mission, and 1024 bps during the Giacobini-Zinner comet encounter. The bit rate then
successively dropped to 512 bps (on 9/12/85), 256 bps (on 5/1/87), 128 bps (on 1/24/89)
and finally to 64 bps (on 12/27/91). An update to the ICE mission was approved by NASA
headquarters in 1991. It defines a Heliospheric mission for ICE consisting of
investigations of coronal mass ejections in coordination with ground-based observations,
continued cosmic ray studies, and special period observations such as when ICE and Ulysses
are on the same solar radial line.
As of January 1990, ICE was in a 355 day heliocentric orbit with an aphelion of 1.03 AU, a perihelion of 0.93 AU and an inclination of 0.1 degree. This will bring it back to the vicinity of the earth-moon system in August, 2014. Termination of operations of ISEE 3 was authorized 5 May 1997. In March 2014, German radio amateurs were able to pick up the beacon signal of the probe. A crowd-funded effort was made to reactivate the old craft. Although communications could be established and instruments reactivated, the propulsion system failed to work. On 11 August 2014, the probe performed a fly-by within 15600 km of the moon.
