Official name | INTELSAT 510 |
Alternative name | Intelsat VA F-10 |
Cospar ID | 1985-025A |
Norad ID | 15629 |
Launch date | 1985-03-22 |
Launch site | AFETR |
Launch vehicle | Atlas-G Centaur-D1AR |
Country/Organization | International, Netherlands (NSS) |
Type application | Communication |
Operator | Intelsat / New Skies (NSS) / Columbia |
RCS size | LARGE |
Decay date | ON ORBIT |
Period (min) | 1465.17 |
Inclination (deg) | 14.37 |
Perigee (km) | 36223 |
Apogee (km) | 36485 |
Eccentricity | 0.00360345491555262 |
Mean motion (revs. per day) | 0.982821106083253 |
Semi-Major axis (km) | 42732.135 |
Raan (deg) | 345.8589 |
Arg of perigee (deg) | 7.3671 |
Shape | Hex Poly + 2 Pan |
Mass (kg) | 1088.21 |
Height (m) | 6.4 |
Width (m) | 2 |
Depth (m) | 2 |
Span (m^2) | 15.57 |
Lifetime | 9 years |
Contractors | Ford Aerospace |
Equipment | 26 C-band transponders, 6 Ku-band transponders |
Propulsion | Star-37XF |
Configuration | Intelsat-5 bus |
Power | 2 deployable solar arrays, batteries |
Satellite | COSPAR | Date | LS | Launch Vehicle | Remarks | |
---|---|---|---|---|---|---|
INTELSAT 510 | 1985-025A | 1985-03-22 | AFETR | Atlas-G Centaur-D1AR | ||
INTELSAT 511 | 1985-055A | 1985-06-30 | AFETR | Atlas-G Centaur-D1AR | ||
INTELSAT 512 | 1985-087A | 1985-09-28 | AFETR | Atlas-G Centaur-D1AR | ||
NSS 513 (INTELSAT 513) | 1988-040A | 1988-05-17 | FRGUI | Ariane-2 | ||
INTELSAT 515 | 1989-006A | 1989-01-27 | FRGUI | Ariane-2 |
