Official name NADEZHDA 7
Alternative name Nadezhda-M
Cospar ID 2002-046A
Norad ID 27534
Launch date 2002-09-26
Launch site PKMTR
Launch vehicle Kosmos-3M
Country/Organization Russia
Type application Navigation / SAR Transponder
RCS size LARGE
Decay date ON ORBIT
Period (min) 104.89
Inclination (deg) 82.94
Perigee (km) 964
Apogee (km) 1015
Eccentricity 0.0257705912076806
Mean motion (revs. per day) 13.7286681285156
Semi-Major axis (km) 7367.635
Raan (deg) 179.7174
Arg of perigee (deg) 314.2568
Shape Cyl + 1 Arm
Mass (kg) 870
Diameter (m) 2.1
Height (m) 5
Span (m^2) 17
Contractors NPO Prikladnoi Mekhaniki (NPO PM)
Equipment RK-SM
Configuration KAUR-1
Power Solar cells, batteries

Nadezhda-M is a hybrid version of the Nadezhda space craft series, which still uses the KAUR-1 bus of the earlier versions, but features the new onboard search and rescue transponder, RK-SM. Follow-on RK-SM units will use Sterkh, the new microsatellite bus developed in Omsk.

Satellite COSPAR Date LS Launch Vehicle Remarks
NADEZHDA 7 2002-046A 2002-09-26 PKMTR Kosmos-3M
