Official name EUTE 117W B
Alternative name Eutelsat 117 West B
Cospar ID 2016-038B
Norad ID 41589
Launch date 2016-06-15
Launch site AFETR
Launch vehicle Falcon-9 v1.2
Country/Organization Mexico → International
Type application Communication
Operator Satelites Mexicanos S.A. de C.V. (Satmex) → Eutelsat Americas
RCS size LARGE
Decay date ON ORBIT
Period (min) 1436.16
Inclination (deg) 0.01
Perigee (km) 35786
Apogee (km) 35789
Eccentricity 4.1914076143905E-05
Mean motion (revs. per day) 1.00267379679144
Semi-Major axis (km) 42165.635
Raan (deg) 158.8547
Arg of perigee (deg) 304.9914
Shape Box + 2 Pan
Mass (kg) 1963
Height (m) 4.8
Width (m) 2.1
Depth (m) 2.1
Span (m^2) 32.6
Lifetime 15 years
Contractors Boeing Satellite Systems
Equipment 48 Ku-band transponders, WAAS payload
Propulsion 4 × XIPS-25
Configuration BSS-702SP
Power 2 deployable solar arrays, batteries

Satelites Mexicanos S.A.B. de C.V. (Satmex) announced in July 2013, that it has contracted with the construction of Satmex 9 to Boeing Satellite Systems as part of a four satellite ABS/SATMEX deal. SATMEX was acquired be Eutelsat in 2014 and was rebranded Eutelsat Americas. In May 2014, it was renamed Eutelsat 117 West B.

Eutelsat 117 West B is a satellite with 48 Ku band 36 MHz equivalent transponders, capable of serving all of Satmex?s Latin American customers in the video, telecommunications and government sectors. It will also carry a Wide-Area Augmentation System ((WAAS-GEO 5). The WAAS hosted payload will enable the U.S. Federal Aviation Administration (FAA) to enhance aviation safety. Co-located with Satmex 8 at the 116.8° W orbital position, Eutelsat 117 West B is designed to provide capacity to Satmex?s DTH and telecommunication customers. The satellite was constructed on the BSS-702SP bus - a version that features an all-electric propulsion system.

The satellite is part of a joint order by ABS and SATMEX of four BSS-702SP satellites. The first two satellites, ABS 3A and Satmex 7, are scheduled to be delivered together in late 2014 or early 2015.

Satellite COSPAR Date LS Launch Vehicle Remarks
EUTE 117W B 2016-038B 2016-06-15 AFETR Falcon-9 v1.2 with ABS 2A
