Official name MERIDIAN 10
Alternative name Meridian-M No. 20L
Cospar ID 2022-030A
Norad ID 52145
Launch date 2022-03-22
Launch site PKMTR
Launch vehicle Soyuz-2-1a Fregat
Country/Organization Russia
Type application Communication
RCS size LARGE
Decay date ON ORBIT
Period (min) 717.84
Inclination (deg) 62.65
Perigee (km) 1961
Apogee (km) 38396
Eccentricity 0.902817355105682
Mean motion (revs. per day) 2.00601805416249
Semi-Major axis (km) 26556.635
Raan (deg) 222.4756
Arg of perigee (deg) 273.7079
Shape Box + 2 Pan
Mass (kg) 2000
Height (m) 4
Width (m) 2
Depth (m) 2
Span (m^2) 10
Lifetime 7 years
Contractors ISS Reshetnev (ex NPO Prikladnoi Mekhaniki, NPO PM)
Configuration 3-Axis stabilized Uragan-M bus ?
Power 2 deployable solar arrays, batteries

Meridian-M is an improved version of the Meridian communications satellites reported to be the replacement for all the Molniya-1T, the Molniya-3 and Molniya-3K satellite series and possibly also for the communication component of the Parus. They are launched into highly eccentric Molniya-orbits.

Meridian is the highly eccentric orbit (HEO) component of the Integrated Satellite Communications System (ISSS), where they work in conjunction with the geostationary Raduga-1M (Globus-M) satellites.

The bus structure is reportedly pressurized, possibly based on the Uragan-M bus. Meridian satellites carry three transponders operating in different frequency bands.

The Meridian series was to end with the seventh launch. It was to replaced by a new series beginning in 2016, which will feature unpressurized busses. Instead, in February 2016, a new batch of four similar but slightly improved Meridian-M satellites was ordered, with the first to be launched in 2018. The first of these was launched in July 2019. In May 2020, another two satellites were ordered.

Satellite COSPAR Date LS Launch Vehicle Remarks
MERIDIAN 8 2019-046A 2019-07-30 PKMTR Soyuz-2-1a Fregat
MERIDIAN 9 2020-015A 2020-02-20 PKMTR Soyuz-2-1a Fregat
MERIDIAN 10 2022-030A 2022-03-22 PKMTR Soyuz-2-1a Fregat
