Official name SPACEWAY 3
Alternative name Spaceway 3
Cospar ID 2007-036A
Norad ID 32018
Launch date 2007-08-14
Launch site FRGUI
Launch vehicle Ariane-5ECA
Country/Organization USA
Type application Communication
Operator DirecTV (#1, #2); Hughes Network Systems (#3)
RCS size LARGE
Decay date ON ORBIT
Period (min) 1452.52
Inclination (deg) 3
Perigee (km) 36100
Apogee (km) 36115
Eccentricity 0.000207713079000208
Mean motion (revs. per day) 0.99138049734255
Semi-Major axis (km) 42485.635
Raan (deg) 81.7675
Arg of perigee (deg) 114.4888
Shape Box + 2 Pan
Mass (kg) 6075
Height (m) 5.1
Width (m) 3.2
Depth (m) 3.2
Span (m^2) 40.9
Lifetime 13 years
Contractors Boeing
Equipment 72 Ka-band transponders (#1, #2), regenerative Ka-band payload (#3)
Propulsion R-4D, 4 × XIPS-25 Ion engines
Configuration BSS-702
Power 2 deployable solar arrays, batteries

Hughes Network Systems is developing a global satellite network named Spaceway, which will provide high-bandwidth and high-speed communications for broadband and multimedia applications.

The North American constellation will include two BSS-702 geosynchronous satellites and one in-orbit spare. The satellites are the next generation in satellite communications technology, transmitting and receiving up to 100 times faster than conventional telephone lines. Spaceway North America will operate in Ka-band.

Due to less than expected demand, DirecTV Group Inc.may use two new satellites to provide more for high-definition TV, programming instead of an Internet-access service that the company had planned. It may also use them to offer both services. Boeing modified the first two satellites for bent-pipe Ka-band communications for use in high definition television and disabled the regenerative on-board processing of the original system that was to be used for broadband satellite communications.

The first of the three satellites was scheduled to be launched in 2003 by Sea Launch on a Zenit-3SL (2) booster but was delayed to 2005. The Spaceway 2 satellite has been moved to an Ariane-5ECA launch vehicle to enable a launch of both Spaceway 1 and 2 in 2005. Spaceway 3 was moved in 2007 also to Ariane-5 in the aftermath of a Zenit-3SL (2) launch failure.

In December 2019 the 14-year-old Spaceway 1 suffered a crippling battery malfunction that the company fears could cause it to explode. Spaceway-1, operating only directly on the solar arrays was maneuvered out of the geostationary orbit into a gravyard orbit to passivate it before it entered the February eclipse period.

Satellite COSPAR Date LS Launch Vehicle Remarks
SPACEWAY 1 2005-015A 2005-04-26 SEAL Zenit-3SL (2)
SPACEWAY 2 2005-046B 2005-11-16 FRGUI Ariane-5ECA with Telkom 2
SPACEWAY 3 2007-036A 2007-08-14 FRGUI Ariane-5ECA with BSat 3a
