Official name WORLDVIEW 3
Alternative name WorldView-3
Cospar ID 2014-048A
Norad ID 40115
Launch date 2014-08-13
Launch site AFWTR
Launch vehicle Atlas-5(401)
Country/Organization USA
Type application Earth observation
Operator DigitalGlobe
RCS size LARGE
Decay date ON ORBIT
Period (min) 96.95
Inclination (deg) 97.86
Perigee (km) 608
Apogee (km) 617
Eccentricity 0.0073469387755102
Mean motion (revs. per day) 14.853017019082
Semi-Major axis (km) 6990.635
Raan (deg) 220.6118
Arg of perigee (deg) 143.4306
Shape Hex Cyl + 2 Pan
Mass (kg) 2615
Diameter (m) 2.5
Height (m) 4.3
Span (m^2) 7.1
Lifetime 7.25 years
Contractors Ball Aerospace
Propulsion ?
Configuration BCP-5000
Power 2 deployable solar arrays, batteries

WorldView 2 is an earth observation satellite operating at an altitude of 770 kilometers. WorldView 2 enables DigitalGlobe to offer half-meter panchromatic resolution and 1.8 meter multispectral resolution. The WorldView 2 system allows DigitalGlobe to substantially expand its imagery product offerings to both commercial and international customers with a more commercially desirable, higher performance product. Added spectral diversity provides the ability to perform precise change detection and mapping. WorldView 2 incorporates the industry standard four multispectral bands (red, blue, green and near-infrared) and also includes four new bands (coastal, yellow, red edge, and near-infrared).

The WorldView 2 telescope has a 110 cm aperture and flys at a higher altitude of 770 km. It provides the same panchromatic half-meter resolution imagery as WorldView 1, in addition to 1.8 meter multispectral resolution imagery.

In 19 July 2016, Worldview-2 was involved in a debris-causing event, but the satellite remained operational.

In August 2010 a mostly identical WolrdView 3 was ordered for launch in 2014. This satellite has an additional infra-red capability. From its lower orbit of 617 km, it has a ground resolution of 0.31 m.

Satellite COSPAR Date LS Launch Vehicle Remarks
WORLDVIEW 2 2009-055A 2009-10-08 AFWTR Delta-7920-10C
WORLDVIEW 3 2014-048A 2014-08-13 AFWTR Atlas-5(401)
