Official name HJ-2B
Alternative name Huan Jing 2B
Cospar ID 2020-067B
Norad ID 46479
Launch date 2020-09-27
Launch site TSC
Launch vehicle CZ-4B
Country/Organization China
Type application Earth observation
Operator CRESDA
RCS size LARGE
Decay date ON ORBIT
Period (min) 97.52
Inclination (deg) 97.92
Perigee (km) 639
Apogee (km) 642
Eccentricity 0.00234192037470726
Mean motion (revs. per day) 14.766201804758
Semi-Major axis (km) 7018.635
Raan (deg) 228.4317
Arg of perigee (deg) 142.6558
Shape Box + 2 Pan
Mass (kg) 510
Height (m) 1.4
Width (m) 1
Depth (m) 1
Contractors DFH Satellite Co. Ltd of CAST
Configuration CAST2000
Power 2 deployable solar arrays, batteries

HJ 2A and 2B (Huan Jing = Environment) satellites are the second generation of small chinese Earth observation satellites operated by the China Centre for Resources Satellite Data and Application (CRESDA). The satellite constellation is composed of a number of small satellites, the ground system, and the application system. It will provide all-weather (3 to 100 m meter) imagery.

These are optical remote sensing satellites with high mobility, precision control and stability, and long lifespans.

The satellites can provide 16-meter multispectral, 48-meter hyperspectral and infrared image data.

They will support the monitoring of natural disasters and land utilization, regulation and protection of water resources, dynamic monitoring of crop areas and assessment of yield, as well as quake emergency rescue.

They will form a co-orbital constellation with the Gaofen-1 and Gaofen-6 satellites.

Satellite COSPAR Date LS Launch Vehicle Remarks
HJ-2A 2020-067A 2020-09-27 TSC CZ-4B with HJ 2B
HJ-2B 2020-067B 2020-09-27 TSC CZ-4B with HJ 2A
